Grundfos Multistage Centrifugal Pump MTR3-23/23 D-M-A-AQQV

(All specifications Subject to Buyer's Verification) (2) New Inbox Units Available

Manufacturer: Grundfos

Part Number: 98821820

Rated pump speed: 3472 RPM

Rated flow: 15.4 US GPM

Rated head: 545.6 ft

Chambers: 23

Impellers: 23

Number of reduced-diameter impellers: 0

Drainage back to tank (Yes)

Pump orientation: Vertical

Code for shaft seal: AQQV

Approvals: CE EAC, UKCA, Morroco

Approvals for motor: CE,EAC,UKCA,SEPRO,Morocco

Energy approvals for motor: CE,CC,Singapore,JiS,Aust./N.Z.

Curve tolerance: ISO9906:2012 3B

Pump version: D

Pump head Cast iron, EN 1561 EN-GJL-200

Impeller: SS, EN 1.4301, AISI 304

Material code: A

Maximum ambient temperature 140* F

Maximum operating pressure: 362.59 PSI

Max pressure at stated temperature: 363 PSI / 194* F

Type of connection: SQUARE/Rp

Size of outlet port: 1-1/4"

Immersion depth: 21.2 Inches

Flange size for motor: FT330

Net weight: 74.9 lbs

Gross weight: 83.7 Lbs.

Shipping volume: 4.56 ft3

Environmental approvals WEEE
